Drywall Reveal Plasterboard®

For the perfect finishing of reveals in any renovation or new construction project

What is the Ripstaal Drywall Reveal Plasterboard?

The Drywall Reveal Plasterboard from Ripstaal is a time-saving solution for the perfect finishing of reveals in any renovation or new construction project. The Ripstaal Drywall Reveal Plasterboard is very easy to install and eliminates the need for carpentry and painting. This saves an enormous amount of time!

Ripstaal Drywall Reveal Plasterboard®
Benefits

Time-saving complete solution

Fast and perfect finishing of reveals in any renovation or new build project. 60% savings on labour and drying time is a thing of the past. Available in 12.5 mm plasterboard with PVC corner protector and PVC corner protector with fabric strip. Optionally available in 9.5 mm plasterboard with PVC corner protector.

Perfect finishing of reveals

Guaranteed sleek finish. No trouble with shrinkage cracks in the reveals. Plastering cannot tear loose from the frame thanks to window connection profile.
Carpentry will be redundant.

Quick and easy to install

In 6 Simple steps.

No need for carpentry or painting

The soft PVC flange on the U-profile always provides a tight connection to the frame. Because of this perfect connection there is no need for carpentry. And because of this there is no need to paint either.

Applicable in any renovation or new construction project

Because of the different versions, the Drywall Reveal Board can be used in any building project. From dry construction to wet finishing. The desired Drywall Reveal Board is available for every job. Ask our sales department about the possibilities.

Available in various sheet materials and sizes

The Drywall Reveal Board is available as standard plasterboard, hydro plate and diamond board. Standard dimensions are available from 150 mm width, increasing by 50 mm each to 400 mm. Length 2600 and 3000 mm. Custom-made panels are available up to a maximum width of 1200 mm upon request (from 50 pieces).

Drywall Reveal Plasterboard

In 6 simple steps
(1) Measure the length and width of the reveal and make the Drywall Reveal and the connection profile to size.
(2) Stick the connection profile against the frame and place the Drywall Reveal in the profile.
(3) Inject the backside of the Drywall Reveal with an installation- or glue foam that does not expand. Using a level, ensure that the Drywall Reveal is perpendicular to the frame.
(4) Once the adhesive foam has cured, the seams between the Drywall Reveal and the window sill should be glued.
(5) The walls next to the day side can now be plastered. The day lace itself is not required!
(6) The Drywall Reveal can be finished with almost all decorative materials.

Specifications

Regularly available in lengths of 3 metres and 2.60 metres
Standard in 12.5 mm A-sheet/Diamond Board with PVC corner protector and PVC corner protector with fabric strip. Also available in 9.5 mm A-sheet with PVC corner protector.
Different versions for indoor and outdoor use (standard plasterboard and Diamond Board)
